TXQ M 1500Aeration

FEATURES

  • Roof exhaust fan to extract air directly outside.
  • IP24 protection degree.
  • IP44 side cabinet protection degree4.
  • Maximum air temperature 60°C.
  • Quick and functional installation thanks to the electrical connection and mounting from the inside of the control cabinet.
  • Energy saving and reduced noise.
  • Painted steel body grey RAL 7035.
  • Safety protection grille.
  • Ball bearing motor impeller self-cleaning backward curved blades.
  • Adjustable speed through industrial controllers RGM2 or RGE (optional).
  • Velocità regolabile con l’utilizzo dei regolatori RGM 2 oppure RGE (opzionali).
  • Necessary to provide for installation an air intake grille in the lower part of the control cabinet.
  • In accordance with Standard EN 60335-2-80.

DIMENSIONS

Product versions

Slide the table to the right

Model Code Voltage (V) Frequency (Hz) Flow rate (m³/h) Power (W) Noisiness dB(A)3m Weight (Kg) Nom. curr.(A) IP grade roof fan IP grade side cabinet
Model Code Voltage (V) Frequency (Hz) Flow rate (m³/h) Power (W) Noisiness dB(A)3m Weight (Kg) Nom. curr.(A) IP grade roof fan IP grade side cabinet
TXQ M 1500 0075830 230 50/60 1470/1560 150 57 7,5 0,75 IP24 IP44
TXQ M 1500 CA (Cappa di aerazione senza motore) 0075860 0 0 0 0 0 4,5 0 IP24 IP44

Further information about the product: Aeration - TXQM1500
